SD100 Orion Plus
Touch Panel Computers
-
10" screen
-
1D & 2D
-
5G
-
9,000 mAh
-
Android 11
-
Bluetooth 5.1
-
Camera
-
GPRS
-
IP65
-
Laser aimer
-
Location
-
Megapixel
-
NFC
-
SD
-
Touchscreen
-
USB-C
-
Warranty 2 Years
-
WIFI Dual Band
| Part Number | Description | EOL date | EOM date |
|---|---|---|---|
| SD-SD100-PLUS | SD100 Plus 10" Tablet 2.2Ghz 4GB/64GB, 2D CMOS Mega Pixel imager with Laser Aimer (CM6x), BT, WiFi, 5G, GPS, NFC and Camera. Incl USB cable and multiplug adapter (Orion III). OS: Android 11 GMS (AER). | 8/17/2026 | 8/17/2031 |
Published on:
The following products will be discontinued at set dates due to having better alternatives or outdated technology.
Recommendation of Alternative Product:
NQuire 10 TrygonEOL date: product discontinuation date, the last day of accepting order for this product.
EOM date: service & support discontinuation date, the last day of providing software upgrade, parts & repair service for this product.
Say hello to our first 5G Android tablet for all your 1D and 2D scanning needs. This 10.1-inch robust tablet makes for the ultimate scanning companion from the shop to the stock floor.
Features
-
Supports.
1D and 2D barcodes. -
Software.
Built on Android 11 GMS (AER). -
Touch screen.
10.0 inch (1920 x 1200) 5 point capacitive touch screen. -
Processor.
Octa core 2.2 GHz CPU. -
Memory.
4GB RAM and 64GB Flash memory. -
Offers.
WiFi 802.11 a/b/g/n/ac (2.4GHz & 5GHz), Bluetooth 5.1, GPS, camera, NFC, GSM, WCDMA. -
Accessories.
Support hand strap for ease of use. Optional charging cradle and vehicle cradle.
Technical Specifications
-
Data Capture
1D All major 1D symbologies 2D All major 2D symbologies -
Performance
Current Operating System Android 11, GMS, Android Enterprise Recommended (AER) Memory Flash 64GB Memory RAM 4GB Processor 2.0 GHz octa-core -
Physical
Audio Front dual stereo speakers, Volume 90db±3db (test distance 10cm) Audio Jack 3.5mm earphone jack Battery Type 9000 mAh Dimensions 254(W) x 176(D) x 17.4(H) mm Display/Touch Panel 10” (1200 x 1920), IPS highlight screen, 5 points capacitive touchscreen Expansion Slot 1 SD card slot Expected Battery Life Typical working time not less than 10 hours Expected Charge Time Fast charging, full charging time <4 hours Front camera 5 MP Interfaces USB-C Keypad 12 keys Notifications Sound, Vibration, LED Rear camera 13 MP, Auto focus, High brightness LED flash Sensors G-sensor, Ambient light sensor, Proximity sensor SIM/TF 2 Micro SIM card Weight 800 g (with battery) -
Wireless
GPS GPS, BD, GLONASS NFC ISO14443A/B , ISO15693 NFC: Reading Distance 0 to 5 cm WLAN RADIO IEEE 802.11 a/b/g/n/ac 2.4G 5G dual frequency WPAN RADIO Bluetooth 5.1 BLE WWAN RADIO FDD-LTE B1/B3/B5/B7/B8, TDD-LTE B38/B39/B40/B41, TDSCDMA B34/B39, WCDMA B1/B2/B5/B8, GSM B2/B3/B5/B8, CDMA 1 x/CDMA2000 BC0/BC1 -
Environmental
Drop 1 m Electro Static Discharge (ESD) ±8 kV (contact discharge), ±15 kV (air discharge) Humidity 5% to 90% IP Rating IP65 Operating Temperature -20°C to 55°C (-4°F to 131°F) Storage Temperature -30°C to 70°C (-22°F to 158°F) -
Certifications
Certifications Hardware CCC, CE -
Warranty
Warranty Standard 2 Years -
Accessories
Accessories Optional Charging cradle, Car cradle Accessories Standard Hand strap
-
Suggested industries
-
Retail
-
Transportation & Logistics
-
Field Service & Utilities
-
Government & Public
-
Available Versions
| Part Number | Description |
|---|---|
| SD-SD100-PLUS | SD100 Plus 10" Tablet 2.2Ghz 4GB/64GB, 2D CMOS Mega Pixel imager with Laser Aimer (CM6x), BT, WiFi, 5G, GPS, NFC and Camera. Incl USB cable and multiplug adapter (Orion III). OS: Android 11 GMS (AER). |
