1.5m drop
-
1D & 2D
-
3.5" screen
-
4G
-
5,200 mAh
-
Android 8.1
-
Bluetooth 4.1
-
Camera
-
GPRS
-
IP65
-
Laser aimer
-
Location
-
Megapixel
-
Micro SD
-
NFC
-
Touchscreen
-
USB-C
-
Warranty 2 Years
-
WIFI Dual Band
SD35 Leo
Mobile Computers
-
1.5m drop
-
1D & 2D
-
3.5" screen
-
4G
-
5,200 mAh
-
Android 8.1
-
Bluetooth 4.1
-
Camera
-
GPRS
-
IP65
-
Laser aimer
-
Location
-
Megapixel
-
Micro SD
-
NFC
-
Touchscreen
-
USB-C
-
Warranty 2 Years
-
WIFI Dual Band
| Part Number | Description | EOL date | EOM date |
|---|---|---|---|
| SD35L-C | 3,5” Mobile computer 2Ghz 2GB/16GB, 2D CMOS imager (N1) with LED Aimer, BT, WiFi, 4G, GPS, NFC, Camera (OS Android 8.1). Incl. USB cable, charging cradle and multi plug adapter (Leo) | 11/2/2023 | 11/2/2028 |
Published on:
The following products will be discontinued at set dates due to having better alternatives or outdated technology.
Recommendation of Alternative Product:
MT67 Sei IIEOL date: product discontinuation date, the last day of accepting order for this product.
EOM date: service & support discontinuation date, the last day of providing software upgrade, parts & repair service for this product.
Embodying the ‘less is more’ motto, the SD35 Leo is a reliable mobile scanning solution that suits every type of budget. Its ergonomic design and keyboard fit right at home in your warehouse or as part of your logistical process.
Features
-
Supports.
1D and 2D barcodes -
Software.
Built on Android 8.1 -
Display.
3.5 inch (640 x 960) high-definition screen -
Processor.
Octa core 2.0GHz CPU -
Memory.
2GB RAM and 16GB ROM memory -
Offers.
Wi-Fi 802.11 a/b/g/n (2.4GHz & 5GHz), Bluetooth 4.1, camera, NFC, GSM, WCDMA
Technical Specifications
-
Data Capture
1D Auspost, Bpo, Canpost, Codabar, Code11, Code128, Code32, Code39, Code93, Dutchpost, Ean13, Ean8, Ean128, Int25, Isbt, Iata25, Japost, Msi, Ocr, Planet, Postnet, Strt25, Tlc39, Trioptic, Upca, and Upce 2D Aztec, Codablock, Code49, Composite, Datamatrix, Maxicode, Micropdf, Pdf417, Qr, and Rss -
Performance
Current Operating System Android 8.1 Memory Flash 16GB Memory RAM 2GB Processor 2.0 GHz octa-core -
Physical
Audio Front dual stereo speakers, Volume 90db±3db (test distance 10cm) Battery Type 5200 mAh Buttons Keyboard, volume buttons, power button, unction buttons (left and right) Dimensions 184(W) x 70(D) x 29.8(H) mm Display 3.5" (640 x 960), IPS highlight screen Expansion Slot 1 Micro PSAM and 1 Micro SD card up to 128 GB Expected Charge Time PE fast charging, full charge time < 4h Interfaces USB-C, OTG Keypad 40 keys Notifications LED, Vibration, Sound Rear camera 13 MP, Auto focus, High brightness LED flash SIM/TF 2 Micro SIM Touch Panel 5 points capacitive touchscreen Weight 290 g (with battery) -
Wireless
GPS GPS, BD, GLONASS NFC ISO1443A/B, ISO15693, NFC reading distance: 0 to 5cm WLAN RADIO IEEE 802.11 a/b/g/n 2.4G 5G dual frequency WPAN RADIO Bluetooth 4.1 BLE WWAN RADIO FDD-LTE B1/B3/B7 TDD-LTE B38/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 CDMA1x/CDMA2000 BC0 -
Environmental
Drop 6 sides can withstand the impact of 1.5 meters drop to concrete Electro Static Discharge (ESD) ±8 kV (contact discharge), ±16 kV (air discharge) Humidity 5% to 95% IP Rating IP65 Operating Temperature -20°C to 60°C (-4°F to 140°F) Storage Temperature -30°C to 80°C (-22°F to 176°F) -
Certifications
Certifications Hardware FCC, CCC, CTA, CE -
Warranty
Warranty Standard 2 Years
-
Suggested industries
-
Retail
-
Transportation & Logistics
-
Warehousing & Distribution
-
Field Service & Utilities
-
Available Versions
| Part Number | Description |
|---|---|
| SD35L-C | 3,5” Mobile computer 2Ghz 2GB/16GB, 2D CMOS imager (N1) with LED Aimer, BT, WiFi, 4G, GPS, NFC, Camera (OS Android 8.1). Incl. USB cable, charging cradle and multi plug adapter (Leo) |
