MT90 Orca Pro

Mobile Computers

Designed and built to go the extra mile, the MT90 Orca Pro offers the very best of our Orca series. As the flagship series’ Pro label, it sports high-end features, such as Android 10 OS, a Qualcomm processor and Android Enterprise Recommended (AER) status, ensuring top support and management. These features come in addition to everything you know and love from the Orca Series.

Choose model:
1D & 2D
Android 10
AER
Megapixel
GMS
Laser aimer
5.0" screen
Touchscreen
Micro USB
4500 mAh
Micro SD
Camera
1.5m drop
IP65
4G
WIFI Dual Band
Bluetooth 4.2
NFC
NFC
GPS
Ndevor
Acuscan
2 years
Warranty 2 Years

Get in touch with us to learn more.

Get in touch Where to buy

Suggested industries

Events
Logistics
Retail
Transportation
Warehousing

Features

Full touchscreen mobile computer.
Like the rest of its series, the MT90 Orca Pro is an Android mobile computer that packs all of the latest hardware into a modern and user-friendly design. It is a light and durable device with a 5" capacitive touch screen. Equipped with a familiar user interface and the exterior of a rugged consumer phone, the MT90 Orca Pro is easy to set up and use right out of the box.

Android Enterprise Recommended (AER).
The MT90 Orca Pro carries Google’s AER seal of approval, signalling it keeps pace with performance and security upgrades to its operating system and core functionality. This label, in combination with Newland’s free MDM Ndevor, enables clients to maintain secure visibility and control over their devices regardless of location. MT90 Orca Pro is also available without Google Mobile Services (GMS), a more streamlined consideration for applications that remain inside the four walls.

Fast Charging and long operating time.
The MT90 Orca Pro has fast charging for its standard 3.8V 4500mAh and its extended capacity 6500mAh battery. Both batteries are replaceable, allowing the user to operate across multiple shifts, day by day.

Powerful and accurate barcode scanning.
The MT90 Orca Pro’s megapixel scanner is built in at the top of the device and can be triggered with a virtual button on the screen, physical buttons on the side of the device or via the trigger on the handle of the PG90 Pistol grip. Newland’s Acuscan function makes the unit ideal for picking applications.

Business-class durability.
The MT90 Orca Pro is built to withstand dusty environments and inevitable bumps and drops. It has Gorilla® Glass, a rating of IP65 and has been drop tested up to 1.5m, ensuring longer and more reliable use.

Accessories that match your operations.
A wide range of accessories for the MT90 Orca Pro are included in the package, namely: single slot charging & communication (USB) cradle, rubber boot, hand strap and wrist lanyard. Various pistol grips, including both UHF and long range, holsters, multi-charging cradles and vehicle cradle kit are also available for the MT90 Orca Series.

Technical specifications

Performance
Image Sensor 1280 x 800 CMOS
Operating System Android 10 - GMS, Android Enterprise Recommended (AER)
Processor Qualcomm Snapdragon 1.8GHz octa-core 64-bit
Memory RAM 4GB
Memory Flash 64GB
Memory Storage Expansion (max.) Micro SD card (max. 128GB)
Illumination White LED
Aiming Red LED (650nm laser diode)
Depth of Field EAN 13 (13mil) 60-420mm
Depth of Field Code 39 (5mil) 102-205mm
Depth of Field PDF417 (6.67mil) 90-173mm
Depth of Field Data Matrix (10mil) 110-275mm
Depth of Field QR (15mil) 40-230mm
Field of View Horizontal 44°
Data Capture
1D All major 1D symbologies, including Code 128, UCC/EAN-128, AIM 128, EAN-8, JAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 25, ITF-6, ITF-14, Deutsche 14, Deutsche 12, COOP 25, Matrix 25, Industrial 25, Standard 25, Code 39, Codabar/NW7, Code 93, Code 11, Plessey, MSI/Plessey, GS1 Databar.
2D All major 2D symbologies, including PDF417, QR Code, Data Matrix, Chinese Sensible Code.
Physical
Dimensions (mm) 155(W) x 78(D) x 20(H)mm
Weight 265g (including battery)
Display 5" full colour (1280x720)
Touch Panel Capacitive touch screen, Gorilla® Glass
Keypad 10 keys (side keys included)
Buttons Side Keys Volume+ ,Volume- , Left Scan Key, Right Scan Key, Power Button, Function Key, Keypad (4 Keys)
Interfaces Micro USB
Battery Type 3.8V, 4500mAh
Notifications Vibrator, speaker and multi-color LED
Power Supply Input AC110 ~ 220V, 50~60Hz
Power Supply Output DC5V,2A
Expansion Slot Micro SD card (max. 128GB)
Camera Front 2.0 megapixels, Rear 13 megapixels, autofocus, with LED flashlight
Environmental
Operating Temperature -20°c to 55°C (-4°F to 131 °F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity 5% to 95% (non-condensing)
Electro Static Discharge (ESD) ±15 kV (air discharge), ±8 kV (direct discharge)
Drop 1.5m
IP Rating IP65
Wireless
WWAN RADIO 2G: GSM (850/900/1800/1900MHz) 3G: WCDMA (B1, B2, B5, B8),TD-SCDMA (B34, B39), CDMA 1x/EVDO (BC0) 4G: TDD-LTE (B38, B39, B40, B41(100m)), FDD-LTE (B1, B2, B3, B5, B7, B8, B2, B28a&b)
WLAN RADIO IEEE 802.11 a/b/g/n/ac, 2.4GHz and 5GHz
WPAN RADIO Bluetooth 4.2 LE, backward compatible
RFID 13.56MHz RFID ISO14443A/B, Ml FARE, FeliCa, NFC Forum Tags, ISO15693
GPS GPS (AGPS), GLONASS
Accessories
Standard Battery, AC adapter, USB cable
Optional Charging Cradle, Pistol Grip, Long Range Pistol Grip, UHF Pistol Grip, Rubber Boot, Wrist Strap, Hand Strap, 3 Slot Cradle, 4 Slot Battery Charger, High Capacity Battery
Software
MDM (certified) Ndevor, SOTI, Airwatch
MDM (certified) Ivanti
Terminal Emulation (compatible) StayLinked
Configuration Tools Ndevor
Warranty
Standard 2 years

Documents

Name View Type
MT90 Orca Pro - print version MT90 Orca Pro.pdf View Datasheet
API Developer Handbook - Android View External Link
MT90 Orca Pro User Guide View User Guide
Acuscan Brochure View PDF Brochure
EasyConnect User Guide View User Guide
AER compatibility View External Link

Available versions

Partnumber Description
MT9084-2WE MT90 Orca Pro Mobile Computer with 5” Touch Screen, 2D CMOS Mega Pixel imager with Laser Aimer, BT, WiFi, 4G, GPS, NFC, Camera. Incl. USB cable, battery, rubber boot and multi plug adapter. OS: Android 10
MT9084-2WE-C MT90 Orca Pro Mobile Computer with 5” Touch Screen, 2D CMOS Mega Pixel imager with Laser Aimer, BT, WiFi, 4G, GPS, NFC, Camera. Incl. USB cable, battery, rubber boot USB charging & communication cradle and multi plug adapter. OS: Android 10
MT9084-AER-2WE MT90 Orca Pro Mobile Computer with 5” Touch Screen, 2D CMOS Mega Pixel imager with Laser Aimer, BT, WiFi, 4G, GPS, NFC, Camera. Incl. USB cable, battery, rubber boot and multi plug adapter. OS: Android 10 GMS (AER)
MT9084-AER-2WE-C MT90 Orca Pro Mobile Computer with 5” Touch Screen, 2D CMOS Mega Pixel imager with Laser Aimer, BT, WiFi, 4G, GPS, NFC, Camera. Incl. USB cable, battery, rubber boot USB charging & communication cradle and multi plug adapter. OS: Android 10 GMS (AER)
