HT35 Leo II
Mobile Computers
-
1.5m drop
-
1D & 2D
-
4.0" screen
-
4G
-
Android 11
-
Bluetooth 5.0
-
Camera
-
GPRS
-
IP65
-
Laser aimer
-
Megapixel
-
Micro SD
-
NFC
-
Touchscreen
-
USB-C
-
Warranty 2 Years
-
WIFI Dual Band
| Part Number | Description | EOL date | EOM date |
|---|---|---|---|
| SD-HT35-W4 | HT35 Leo II 4” Mobile computer 2Ghz 3GB/32GB, 2D CMOS imager (CM60), BT, WiFi, 4G, GPS, NFC and Camera. Incl. USB cable, charging cradle (incl. SD-ADP004), Hand Strap, Pistol Grip and multiplug adapter (SD-ADP003). OS: Android 11 | 5/27/2024 | 5/27/2029 |
Published on:
The following products will be discontinued at set dates due to having better alternatives or outdated technology.
Recommendation of Alternative Product:
N7 Cachalot Pro IIEOL date: product discontinuation date, the last day of accepting order for this product.
EOM date: service & support discontinuation date, the last day of providing software upgrade, parts & repair service for this product.
Embodying the ‘less is more’ motto, the HT35 Leo II is a reliable mobile scanning solution that suits every type of budget. Its ergonomic design and keyboard fit right at home in your warehouse or as part of your logistical process.
Features
-
Supports.
1D and 2D barcodes. -
Software.
Built on Android 11. -
Display.
4 inch (480*800) high-definition capacitive touchscreen. -
Processor.
Octa core 2.0GHz CPU. -
Memory.
3GB RAM and 32GB ROM memory. -
Offers.
Wi-Fi 802.11 a/b/g/n (2.4GHz & 5GHz), Bluetooth 5.0, camera, NFC, GSM, WCDMA.
Technical Specifications
-
Data Capture
1D All major 1D symbologies 2D All major 2D symbologies -
Performance
Current Operating System Android 11 Memory Flash 32GB Memory RAM 3GB Memory Storage Expansion (max.) Micro SD card slot up to 256GB Processor 2.2 GHz octa-core -
Physical
Audio Front dual stereo speakers, Volume 90db±3db (test distance 10cm) Battery Type 7.4 V, 19.24 Wh Buttons Power, scan keys, volume +/- Dimensions 196.4(W) x 74.8(D) x 26.8(H) mm Display 4" (800 x 480), IPS highlight screen Expansion Slot Micro SD card slot up to 256GB Expected Charge Time PE fast charging, full charge time < 4h Interfaces Pogo pins, USB-C, OTG Keypad 40 keys Notifications LED, Vibration, Sound Sensors Proximity sensor, Acceleration sensor, Light sensor SIM/TF Nano SIM card slot *2 Touch Panel 5 points capacitive touchscreen Weight 350 g (including battery) -
Wireless
GPS GPS, BD, GLONASS WLAN RADIO IEEE 802.11 a/b/g/n/ac 2.4G/5G dual band; supports fast roaming WPAN RADIO Bluetooth 5.0 BLE WWAN RADIO FDD LTE B1/B3/B5/B7/B8; TDD LTE B38/B39/B40/B41; WCDMA B1/B2/B5/B8; GSM B2/B3/B5/B8; CDMA1x/CDMA2000 BC0/BC1 -
Environmental
Drop 1.5 meter drop to marble Electro Static Discharge (ESD) ±8 kV (contact discharge), ±16 kV (air discharge) Humidity 5% to 95% (non-condensing) IP Rating IP65 Operating Temperature -20°C to 55°C (-4°F to 131°F) Storage Temperature -30°C to 70°C (-22°F to 158°F) -
Certifications
Certifications Hardware FCC, CCC, CTA, CE -
Warranty
Warranty Standard 2 Years
-
Suggested industries
-
Retail
-
Transportation & Logistics
-
Warehousing & Distribution
-
Field Service & Utilities
-
Configurations & Drivers
Available Versions
| Part Number | Description |
|---|---|
| SD-HT35-W4 | HT35 Leo II 4” Mobile computer 2Ghz 3GB/32GB, 2D CMOS imager (CM60), BT, WiFi, 4G, GPS, NFC and Camera. Incl. USB cable, charging cradle (incl. SD-ADP004), Hand Strap, Pistol Grip and multiplug adapter (SD-ADP003). OS: Android 11 |
