NQuire 750 Stingray
Dokunmatik Ekranlı Mikro Kiosklar
-
1D & 2D
-
4G
-
7" screen
-
Android 7.1
-
Bluetooth 4.0
-
Camera
-
I/O Ctrl
-
Megapixel
-
Micro SD
-
Ndevor
-
NFC
-
PoE
-
RFID
-
Touchscreen
-
USB
-
Warranty 2 Years
-
WIFI Dual Band
| Parça numarası | Açıklama | EOL tarihi | EOM tarihi |
|---|---|---|---|
| NLS-NQUIRE751PRW-7C | NQuire 751 Stingray Customer information terminal with 7" Touch Screen, 2D CMOS Mega Pixel imager with Laser Aimer (CM6x), BT, WiFi and POE. Incl. wall mount bracket and multiplug adapter. OS: Android 7.1. | 19.03.2026 | 19.03.2031 |
Yayımlanma tarihi:
Aşağıdaki ürünler, daha iyi alternatiflere veya eski teknolojiye sahip oldukları için belirlenen tarihlerde kullanımdan kaldırılacaktır.
Alternatif ürün önerisi:
NQuire 750 Stingray IIEOL tarihi: Ürün durdurma tarihi, bu ürün için sipariş kabul edilecek son gün.
EOM tarihi: Servis ve destek durdurma tarihi, bu ürün için yazılım yükseltme, parça ve onarım hizmetinin sağlanacağı son gün.
The NQuire 750 Stingray touch-screen Micro Kiosk offers 7” of screen real estate, especially beneficial for store signage and customer information services. Equipped with the reliable Android 7.1, it offers a feature-rich environment that is tried and tested.
Özellikler
-
Android OS.
The NQuire 750 Stingray uses Android 7.1 OS. With this reliable operating system comes a feature-rich environment for stable apps that are tried and tested. Android 7.1 is an excellent match for the applications most suited to the NQuire 750. Particularly when operating within four walls, fitting the NQuire 750’s PoE (Power over Ethernet) connectivity. -
Free MDM included.
The NQuire 750 Stingray comes with the option of running Newland’s free MDM solution: Ndevor. As a result, the Micro Kiosk lends itself perfectly for the coordination of multiple units. Managing information from a shared database, organizing applications and settings across many individual units, as well as low-touch assistance in troubleshooting can all be managed from a centralized location. -
Mount anywhere.
The NQuire 750 Stingray’s slimline and lightweight design is suitable for mounting on any shelf edge. Options to mount the NQuire series range from shelf to wall and free-standing. Its classic Vesa75 configuration also ensures existing industry standard, 3rd party solutions are compatible. -
Snappy Megapixel Scanning.
Barcode data capture is at the heart of Newland’s Micro Kiosks and so the NQuire 750 is fitted with their own Megapixel scanning technology. This maintains high standards for the scanning of both large and small 1D & 2D barcodes. The Micro Kiosk further includes optimal settings for reading barcodes presented on smartphone and tablet screens. With the scanner set at a 20° angle, it matches the ergonomics of how the user presents codes for scanning. -
Multi-purpose display.
The sharp, full-colour screen on the Stingray is perfect for running animations and live recorded videos when not actively being used. With onboard memory, expanded memory and online options, the choice of content to display is virtually limitless. -
Endless communication possibilities.
With WiFi, Ethernet, Powered Ethernet (PoE) and Bluetooth, this Micro Kiosk offers a variety of standard communication possibilities. Additionally, optional 4G means that the NQuire 750 Stingray can communicate and be communicated with, no matter the circumstance. Adding to that the wide variety of data capture options, such as integrated barcode reading, MSR, NFC and low frequency RFID, application possibilities are endless. Modules can only be ordered pre-mounted to the connector on the left or right side.
Teknik özellikler
-
Veri Yakalama
1D All major 1D symbologies 2D All major 2D symbologies Hedefleme Lazer diyot (625±10 nm) Aydınlatma Beyaz LED (625±10 nm) Görüntü Sensörü 1280 x 800 CMOS Tarama Yöntemleri Algılama Modu Tarama hızı 60 frames per second -
Performans
Mevcut İşletim Sistemi Android 7.1 Flaş Bellek 8 GB eMMC RAM Bellek 2GB DDR3 Bellek Artırma (Maks.) Micro SD up to 128GB İşlemci 1.5 GHz octa-core, 64-bit -
Fiziksel
Ses 82 dB çift kanallı stereo ses Boyutlar (mm) 195(W) x 138.5(D) x 25(H) mm Ekran 7" (1280 x 800) IPS display Genişleme Yuvası Micro SD up to 128GB Ön kamera 5 MP, Sabit odak Giriş Gerilimi 12 VDC (2 A) Arayüzler Mikro USB 2.0, USB 2.0, GPIO, OTG Güç Tüketimi 12 W (max) Ethernet üzerinden güç RJ45 Ethernet, 10/100/1.000BASE-T Güç Kaynağı Girişi AC 110 to 220 V (50 to 60 Hz) Güç Kaynağı Çıkışı DC12 V, 2 A Sensörler Gravity Sensor Dokunmatik Panel 5 inç kapasitif dokunmatik ekran VESA standardı Complies with the standard VESA 75 bracket, enabling easy mounting on shelves and walls -
Kablosuz
RFID ISO/IEC 14443 A/B ISO/IEC 15693; MIFARE 1K/4K; MIFARE DESFire; Sony FeliCa (optional) WLAN RADIO IEEE 802.11 a/b/g/n/ac, 2.4GHz and 5Ghz (optional) WPAN RADIO Bluetooth 4.0 LE, EDR + BLE (optional) -
Çevresel
Nem %5 ila %90 (yoğuşmasız) IP Sınıfı IP54 (sadece ön taraf) Çalışma Sıcaklığı -10 °C ile 50 °C arası (14 °F ile 122 °F arası) Depolama Sıcaklığı -20 °C ile 60 °C (-4 °F ile 140 °F) -
Yazılım
Yapılandırma Araçları Ndevor MDM (sertifikalı) Ndevor, SOTI Terminal Emülasyonu StayLinked, Airwatch -
Sertifikalar
Sertifikalar Donanım IEC 62471, RoHS, CE -
Garanti
Kapsamlı Hizmet Sözleşmesi 3 Yıl, 5 Yıl Garanti Uzatımı +1 yıl, +3 yıl Garanti Koşulları 2 yıl -
Aksesuarlar
Opsiyonel aksesuarlar çoklu güç adaptörü, Masaüstü standı VESA 75, VESA 75 duvar montaj aparatı, MSR okuyucu modülü, NFC okuyucu modülü, 4G modülü, Düşük frekanslı RFID okuyucu modülü Standart aksesuarlar çoklu güç adaptörü, VESA 75 duvar montaj aparatı -
Kutuda neler var?
NLS-NQUIRE751PRW-7C NQuire 750 Stingray, Wall mount bracket, Multiplug adapter
-
Önerilen sektörler
-
Perakende
-
Konaklama ve Eğlence
-
Sağlık
-
Saha Servis ve Kamu Hizmetleri
-
Mevcut versiyonlar
| Parça numarası | Açıklama |
|---|---|
| NLS-NQUIRE751PRW-7C | NQuire 751 Stingray Customer information terminal with 7" Touch Screen, 2D CMOS Mega Pixel imager with Laser Aimer (CM6x), BT, WiFi and POE. Incl. wall mount bracket and multiplug adapter. OS: Android 7.1. |
