HR22 Dorada II
El Tipi Barkod Okuyucular
-
1.2m drop
-
1D & 2D
-
CMOS
-
CPU
-
Dual Interface
-
EasySet
-
IP42
-
Warranty 5 Years
| Parça numarası | Açıklama | EOL tarihi | EOM tarihi |
|---|---|---|---|
| NLS-HR2280-S5 | HR22 Dorada II 2D CMOS Handheld Reader with 3.5 mtr. coiled USB cable. (Smart stand compatible). | 23.07.2025 | 23.07.2030 |
| NLS-HR2280-S8 | HR22 Dorada II 2D CMOS Handheld Reader with 2 mtr. straight RS232 cable and multiplug adapter. (Smart stand compatible). | 23.07.2025 | 23.07.2030 |
| NLS-HR2280-SF | HR22 Dorada II 2D CMOS Handheld Reader with 3.5 mtr. coiled USB cable and foldable smart stand. | 23.07.2025 | 23.07.2030 |
Yayımlanma tarihi:
Aşağıdaki ürünler, daha iyi alternatiflere veya eski teknolojiye sahip oldukları için belirlenen tarihlerde kullanımdan kaldırılacaktır.
Alternatif ürün önerisi:
HR23 Dorada CordedEOL tarihi: Ürün durdurma tarihi, bu ürün için sipariş kabul edilecek son gün.
EOM tarihi: Servis ve destek durdurma tarihi, bu ürün için yazılım yükseltme, parça ve onarım hizmetinin sağlanacağı son gün.
The highest profile successes of the Dorada series have come in industries and applications looking for a 2D scanner at the price of a 1D scanner. Offering a cost-effective handheld scanning solution, the HR22 Dorada II offers an upgrade fitting growing demands by the market.
Özellikler
-
Supporting the step from 1D to 2D.
The HR22 Dorada II is specifically developed to provide a cost-effective scanning solution that allows customers to enjoy the capabilities of a 2D scanner for a price that the market had previously expected of 1D-only scanners. -
Neat design.
The handheld scanner has a clean design that is not out of place on a countertop. The adjustable stand, as well as saving space and keeping your workspace clutter-free, is attractive enough to sit alongside POS equipment in a customer facing environment. -
Aiming at the right code.
The HR22 Dorada II now uses white illumination so the red LED aimers can be even more clearly seen. Ensuring the scanner is correctly lining up the code, it adds an extra level of confidence to the user. -
Durable construction.
The HR22 Dorada II has a more than suitable IP42 rating for its key applications and is drop resistant up to 1.5m. Its durable housing guarantees optimal protection so falls from desktops and countertops are no issue. -
CPU decoding for more codes and more control.
The Dorada II now uses Newland CPU processor decoding. The benefits of CPU-based decoding include improved configurations for data handling, as well as retaining additional flexibility to add more barcode symbologies. This includes Italian Pharma code found in pharmaceutical sales, as well as tracking and Aztec, common in airline boarding passes, ticketing and some retail loyalty. -
Handsfree scanning.
The handheld scanner is autosense ready, meaning it can switch from trigger press to handsfree by docking the scanner in the adjustable stand. Scanner available with stand as a kit.
Teknik özellikler
-
Veri Yakalama
1D All major 1D symbologies, including Code 11, Code 128, Code 39, GS1-128 (UCC/EAN 128), AIM 128, ISBT 128, Codabar, Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-8, EAN-13, ISBN/ISSN, Interleaved 2 of 5, Matrix 2 of 5, Industrial 25, ITF6, ITF-14, Standard 25, China Post 25, MSI Plessey, Plessey, GS1 Databar (RSS). 2D All major 2D symbologies, including PDF417, Micro PDF417, Micro QR, QR Code, Data Matrix, Aztec. Hedefleme Kırmızı LED (625 nm) Alan Derinliği Code 39 (5mil) 50 mm - 115 mm Alan Derinliği Data Matrix (10mil) 35 mm - 125 mm Alan Derinliği EAN13 (13mil) 50 mm - 260 mm Alan Derinliği PDF417 (6.67mil) 50 mm - 120 mm Alan Derinliği QR (15mil) 30 mm - 170 mm Yatay Görüş Alanı 45° Dikey Görüş Alanı 34° Aydınlatma White LED Görüntü Sensörü 640 x 480 CMOS Minimum Baskı Kontrastı 20% Tarama Açısı Aralığı ±55° (QR 15mil) Tarama Yatış Açısı 360° (QR 15mil) Verev Tarama Açısı ±55° (QR 15mil) -
Fiziksel
5VDC Çalışma akımı 190 mA (typical), 201 mA (max) 5VDC Bekleme akımı 35 mA Boyutlar (mm) 145(W) × 101(D) × 68(H) mm Giriş Gerilimi 5 VDC ±%5 Arayüzler USB, RS-232 Bildirimler Bip sesi, LED Güç Tüketimi 950 mW (typical) Ağırlık 111 g -
Çevresel
Ortam Işığı 0 ila 100.000 lüks Düşme 1.2 m Elektrostatik Deşarj (ESD) ±8 kV (doğrudan deşarj), ±15 kV (hava deşarjı) Nem %5 ila %95 (yoğuşmasız) IP Sınıfı IP42 Çalışma Sıcaklığı -20 °C ile 60 °C (-4 °F ile 140 °F) Depolama Sıcaklığı -40 °C ile 70 °C (-40 °F ile 158 °F) -
Yazılım
Yapılandırma Araçları EasySet -
Sertifikalar
Sertifikalar Donanım CE EMC Class B, FCC Part15 Class B, RoHS -
Garanti
Garanti Koşulları 5 yıl
-
Önerilen sektörler
-
Perakende
-
Konaklama ve Eğlence
-
Sağlık
-
Yapılandırmalar ve Sürücüler
Mevcut versiyonlar
| Parça numarası | Açıklama |
|---|---|
| NLS-HR2280-S5 | HR22 Dorada II 2D CMOS Handheld Reader with 3.5 mtr. coiled USB cable. (Smart stand compatible). |
| NLS-HR2280-S8 | HR22 Dorada II 2D CMOS Handheld Reader with 2 mtr. straight RS232 cable and multiplug adapter. (Smart stand compatible). |
| NLS-HR2280-SF | HR22 Dorada II 2D CMOS Handheld Reader with 3.5 mtr. coiled USB cable and foldable smart stand. |
